SIEMENS 6ES7215-1HF40-0XB0 SIMATIC S7-1200F, CPU 1215 FC, COMPACT CPU, DC/DC/RELAY, 2 PROFINET PORTS, ONBOARD I/O: 14 DI 24 V DC; 10 DO RELAY 2 A, 2

Product Categories
Shenzhen Voboal Industrial Automation Co., Ltd.
Contact Now

SIEMENS 6ES7215-1HF40-0XB0 SIMATIC S7-1200F, CPU 1215 FC, COMPACT CPU, DC/DC/RELAY, 2 PROFINET PORTS, ONBOARD I/O: 14 DI 24 V DC; 10 DO RELAY 2 A, 2

Brand Name : SIEMENS

Model Number : 6ES7215-1HF40-0XB0

Certification : CE

Place of Origin : China

MOQ : 1

Price : USD

Payment Terms : L/C, T/T

Supply Ability : 100PS

Delivery Time : 10-12Days

Packaging Details : 11,10 x 13,70 x 8,80CM

Certifications : CE, UL, CSA

Number Of Digital Inputs : 8

Integrated Hmi : Yes

Integrated Diagnostics : Yes

Programming Language : LAD, FBD, STL, SCL, GRAPH

Integrated Web Server : Yes

Communication : PROFINET, PROFIBUS, MPI, Ethernet, USB

Warranty : 1 Years

Operating Temperature Range : -20 to +60 degrees Celsius

Cpu : 1212C, 1211C,1214C, 1215C, 1217C

Ambient Temperature : -25 to +60 °C

Power Supply : 24 V DC

Communication Protocols : PROFINET, Modbus TCP, Ethernet/IP

Operating Temperature : 0°C to +60°C

Integrated Security : Yes

Contact Now

SIEMENS 6ES7215-1HF40-0XB0 SIMATIC S7-1200F, CPU 1215 FC, COMPACT CPU, DC/DC/RELAY, 2 PROFINET PORTS, ONBOARD I/O: 14 DI 24 V DC; 10 DO RELAY 2 A, 2 AI 0-10 V DC, 2 AO 0-20 MA DC

The **Siemens 6ES7215-1HF40-0XB0** is a **Simatic S7-1200F** Compact CPU model, specifically the CPU 1215 FC variant. This CPU is designed with a DC/DC/Relay configuration and features 2 PROFINET ports. Here are the key specifications for this CPU model:

- **Product Code:** 6ES7215-1HF40-0XB0
- **Product Name:** SIMATIC S7-1200F CPU 1215 FC
- **CPU Type:** Compact CPU
- **Network Ports:** 2 PROFINET ports
- **Input/Output Configuration:**
- **Digital Inputs:** 14 DI at 24 V DC
- **Digital Outputs:** 10 Relay Outputs at 2 A
- **Analog Inputs:** 2 AI at 0-10 V DC
- **Analog Outputs:** 2 AO at 0-20 mA DC

### Overview:
- **CPU Type:** Compact CPU suitable for industrial automation applications
- **Network Connectivity:** Equipped with 2 PROFINET ports for communication
- **I/O Configuration:** Includes 14 digital inputs, 10 relay outputs, 2 analog inputs, and 2 analog outputs
- **Digital Inputs:** Accepts 24 V DC input signals
- **Digital Outputs:** Capable of driving 10 relay outputs at 2 A
- **Analog Inputs:** Supports analog input signals ranging from 0-10 V DC
- **Analog Outputs:** Capable of providing analog output signals in the range of 0-20 mA DC

The Siemens 6ES7215-1HF40-0XB0 CPU 1215 FC is a robust Compact CPU in the Simatic S7-1200F series. With its DC/DC/Relay configuration, dual PROFINET ports, and onboard I/O capabilities, this CPU is well-suited for a variety of industrial automation applications. The combination of digital and analog input/output options, along with network connectivity, makes it a versatile and powerful solution for automation tasks.

Product
Article Number 6ES7215-1HF40-0XB0
Product Description SIMATIC S7-1200F, CPU 1215 FC, compact CPU, DC/DC/relay, 2 PROFINET ports, onboard I/O: 14 DI 24 V DC; 10 DO relay 2 A, 2 AI 0-10 V DC, 2 AO 0-20 mA DC, power supply: DC 20.4-28.8 V DC, program/data memory 250 KB
Product family Fail-safe CPUs
Product Lifecycle (PLM) PM300:Active Product
Price data
Price Group 213
List Price Show prices
Customer Price Show prices
Surcharge for Raw Material see also metal factor (further details are available on the help page)
Metal Factor see also metal factor (further details are available on the help page)
Delivery information
Export Control Regulations AL : N / ECCN : EAR99H
Estimated dispatch time (Working Days) 1 Day(s)
Net Weight (kg) 0,436 Kg
Packaging Dimension 11,10 x 13,70 x 8,80
Package size unit of measure CM
Quantity Unit 1 Piece
Packaging Quantity 1
Additional Product Information
EAN 4025515082941
UPC 804766054662
Commodity Code 85371091
LKZ_FDB/ CatalogID ST72
Product Group 4545
Group Code R152
Country of origin China

SIEMENS 6ES7215-1HF40-0XB0 SIMATIC S7-1200F, CPU 1215 FC, COMPACT CPU, DC/DC/RELAY, 2 PROFINET PORTS, ONBOARD I/O: 14 DI 24 V DC; 10 DO RELAY 2 A, 2
